Thermo Scientific ADR1500 Area Dust Monitor
Thermo Scientific

Thermo Scientific ADR1500 Area Dust Monitor

Pine Item #51352

Coronavirus / COVID-19 FEATURED ITEM!

The Thermo Scientific Model ADR1500 Dust Monitor utilizes the highly sensitive light-scattering photometer (nephelometer) technology as used in the Thermo Scientific™ pDR series. The intensity of the light scattered by airborne particles passing through the sensing chamber is linearly proportional to their concentration. This optical configuration produces an optimal response to particles, providing continuous measurements of the concentrations of airborne particles for total particulate and cut-points ranging from PM10 down to PM1.

The ADR1500 incorporates a temperature and relative humidity (RH) sensor coupled with an internal heater to mitigate the positive bias with elevated ambient RH. Additionally, the flow control is truly volumetric and is maintained through digital feedback of the onboard barometric pressure sensor, temperature sensor and calibrated differential pressure across a precision orifice. The principles of true volumetric flow, as incorporated by the ADR1500, result in an accurate sample volume and precise particle cut-point.

Additional Information:

  • The measured concentration of particulate matter is displayed in real-time on the two-line LCD readout display
  • Additional values can be displayed: run start time and date, time-averaged concentrations, elapsed run time and many more
  • Flexible power capabilities allow the ADR1500 to operate on AC (100-240 VAC), external DC (12-24 VDC) or an internal battery
  • Communications options are available for USB, RS-232, analog and wireless capability
  • The compact and durable instrument is ready for rapid deployment and unattended operation
  • A top-mounted handle allows for easy transport and installation with mounting options available for wall, post or tripod locations
Features:

Volumetric flow control

Modular optics and long-life primary HEPA filter for ease of servicing

Multiple power and communications capabilities

Durable weatherproof IP65 enclosure

Applications:

Volumetric flow control

Modular optics and long-life primary HEPA filter for ease of servicing

Multiple power and communications capabilities

Durable weatherproof IP65 enclosure

Quantity must be 1 or more
Email for Quote

Specifications

Technical Specifications

2-sigma Values±0.5% of reading or ±0.0015mg/m3 whichever is larger for 10-second averaging time
Accuracy±5% of reading ±precision) traceable to SAE Fine test dust
Aerodynamic Particle Cut-Point Range1.0 to 10µm with optional cyclone accessories
Alarm Averaging TimeReal-time (1 - 60 seconds) or STEL (15 minutes)
Alarm OutputLoad impedance >100kw Alarm ON = short to ground Alarm OFF = open
Concentration Measurement Range0.001 to 400mg/m³ (auto-ranging)
Data Logging Averaging Periods1 second to 1 hour
DescriptionArea Dust Monitor
Flow Rate Range1.0 to 3.5L/min.
Height (English)21 in.
Height (Metric)431mm
Hertz50/60Hz
Internal Battery Run Time1.2L/min. (heater and alarm constantly on) >24-hour run time
Depth (English)17 in.
Depth (Metric)215mm
Logged DataAveraged concentrations temperature RH barometric pressure time/date and data point number
Optional CyclonesGK 2.05 (Red) primarily for PM4 through PM10 SCC 1.062 (blue) primarily for PM1 through PM4
Particle Size Range0.1 to 10µm
Precision±2% for 1-second averaging time
Real-time Analog Signal0 to 2V and 4 to 20mA with selectable full scale ranges between 0.1 and 400mg/m3; 0-0.1 0-0.4 0-1.0 0-4.0 0-10 0-40 0-100 and 0-400
Real-time Digital SignalConcentration flow temperature relative humidity barometric pressure time date
Repeatability±0.005mg/m3 for 1-second averaging time
Resolution0.1µg/m?
RH correction±0.2% or reading or ±0.0005mg/m3 whichever is larger for 60-second averaging time
Run SummarySite number average and max. concentrations time/date of maximum number of logged points start time/date elapsed time (run duration) a
Scattering Coefficient Range1.1 x 10-6 to 0.6m-1 (approximately) @ l = 880nm
Serial InterfaceHigh speed USB/RS-232 (reserved for wireless applications) 19200 baud
Temperature (English) Operating14° to 122°F
Temperature (Metric) Operating10° to 50°C
Voltage100-240VAC 12/24VDC for solar or auxiliary battery options
Weight (English)28.5 lb.
Weight (Metric)12.9kg
Width (English)17 in.
Width (Metric)431mm
Item DescriptionThermo Scientific ADR1500
