Drager CMS Analyzer
The world's only Chip Measurement System (CMS) makes spot measurements as easy as 1, 2, 3: insert chip - start measurement - read measurement result on the LCD display. The Drager CMS combines the advantages of the Drager-Tubes ® with those of an optoelectronic analysis system. Two components define the system: the analyzer and the substance-specific chip.
The Drager Chip Measurement System (CMS) is one of the most accurate and reliable portable detection systems currently available for measuring spot concentrations.
It combines an electronic based analyzer with substance specific chips. Each substance specific chip contains 10 individual tests/capillaries, these are filled with a reagent system and is based on Draegers 60+ years experience in colometric chemistry. More than 55 gas-specific chips are available. The CMS Analyzer can store the results of 50 measurements by the DataRecorder integrated within the analyzer, together with relevant data, i.e. measurement substance, concentration, date, time and site of measurement.
The analyzer contains a pump mechanism, microprocessor, optics, and software. The optics read the barcode on an inserted chip and menu-driven instructions for the test appear on the analyzer's LCD. Each analyzer includes a data recorder that will hold the last 50 determinations in memory along with the time/date of sample and a location code.
Accurate and chemical specific
Integrated flow sensor for constant mass flow
Resistant to temperature and humidity effects
Precision optics detect the smallest reaction
Factory-calibrated chemical-specific chips
No interfering compounds
LCD text in English German French or Spanish
Gas and Vapor Measurement
Confined Space Entry
|Data Capacity||Stores up to 50 measurements|
|Power Supply||4 x 1.5 Volt (AA) alkaline batteries|
|Battery Duration||450 minutes of analysis time (typically greater than 100 measurements)|
|Operational Temperature||32-104°F (0-40°C)|
|Dimensions||US: 8.0 x 3.6 x 1.7 in. Metric: 20.3 x 9.14 x 4.3 cm|
